Silver 150mm Bimetal Thermometer Dial 200C Stainless Steel For Hot Water Tanks

Name: Silver 150mm Bimetal Thermometer Dial 200C Stainless Steel For Hot Water Tanks
Brand: WESEN or Customized
Price: 1 USD

Buy cheap Silver 150mm Bimetal Thermometer Dial 200C Stainless Steel For Hot Water Tanks product

Brand Name : WESEN or Customized

Model Number : M14.01.150.N

Certification : CE, ISO

Place of Origin : China

MOQ : 100 Pieces

Price : Negotiable

Payment Terms : T/T

Supply Ability : 20000 Pieces per Month

Delivery Time : 3~4 Weeks

Packaging Details : Carton

Size : 150mm

Mount : Bottom

Temperature Range : 200 °C or customized

Case Material : SUS 304

Connection : PT, NPT, G, BSP

Stem Dia. : 6mm, 8mm, 10mm

Stem Length : 30cm (customized)

Lens : PC Glass

Color : Silver

Accuracy : 1.0

Contact Now

150mm 0-200 °C Stainless Steel Bimetal Thermometer For Hot Water Tanks

Description

The standard scope of delivery of the model A43 includes a thermowell. The thermowell can be operated with an operating pressure up to a maximum of 6 bar. The model M14 is manufactured to tolerance class 2 in accordance with EN 13190 and thus offers the required indication accuracy for heating technology.

Applications

Heating systems

Hot water tanks

Solar collectors

Heat transfer stations

Special features

Reliable and cost-effective

Indication accuracy class 2 in accordance with EN 13190

Scale ranges from -30 ... +120 °C

**Specifications**
Nominal size	150mm
Accuracy	1.0
Temperature range	0-200 °C (customized)
Working range	Full scale value
Case	Steel
Measuring element	Bimetal coil
Connection location	Bottom mount
Stem	Aluminium
Thermowell	Copper alloy, removable, friction fit
Dial	Aluminium
Window	Plastic, glass
Options	Other scale ranges Slip-on bezel, nickel-plated Removable brass thermowell with retainer screw

Silver 150mm Bimetal Thermometer Dial 200C Stainless Steel For Hot Water Tanks

Ordering information
Model / Dial size / Scale Range / Process connection / Stem dia. & length / Options

Silver 150mm Bimetal Thermometer Dial 200C Stainless Steel For Hot Water Tanks
